The low-odor eco solvent SX inks offer a wide color gamut, high vividness, high density, excellent outdoor durability and low running costs. Overall performance of SX inks meets the customers demand for higher productivity and better workplace environment.
SX inks deliver vivid and rich colors with the same wide color gamut as GX inks.
Even with its low odor characteristic, SX inks boast excellent outdoor durability.
The SX inks achieve high-density colors and details in dark areas. The E-64s meets customers’ needs for sharp, clear and bright backlit signs.
The 4th generation of Smart Pass Technologyeffectively reduces overspray and eliminates pass-to-pass banding. Optimizing the effect for each print mode, SP4 brings superb image quality to versatile applications.
Dynamic Dot Printing Technology controls and optimizes dot size to produce rich, bold and glossy colors with fine details. DDP also creates high density printing without any loss in speed, giving the ColorPainter E-64s backlit film capabilities.
We enhanced the nozzle mapping function to SNM3 in order to further minimize down times generated when missing dots are found on the printout. In addition to manual configuration, the nozzle numbers can now be set automatically.
Automatic Print Adjustment performs both media advance and bi-directional position adjustment. The E-64s ensures high quality printing for everyone even if it is a novice.
Developed specifically for the ColorPainter printers, CP_Manager, the bundled controller software, allows operators to operate printers from a PC, tablet or smartphone. Operators can communicate and manage the E-64s by email and Twitter through CP_Manager.
SSS minimizes the damage on the print surface due to the print heads touching the media. You can choose from four operating modes according to your needs. When contact between the print heads and the media is detected, you can quickly pause the job, correct the media, and then resume the print job without canceling it. This reduces wasted time, ink and media.
The ColorPainter E-64s comes with ONYX RIPCenter OKI Edition featuring an easy-to-use intuitive interface. ONYX RIPCenter OKI Edition helps you produce consistent high-quality prints from the first day of installation.
Higher Speed Printing With Rich Color Density
While other prints lose density as they go faster due to small drop sizes and low viscosity inks, the new ColorPainter E-64s uses high viscosity inks and an ultra modern piezo-inkjet head to deliver outstanding image quality and no color density loss.
OKI’s improved dot pattern enables razor sharp, crisp images at all print modes. Choose between fine-detail modes with unmatched print speeds, or high-resolution print modes with less grain.
The air flow inside the printer has been redesigned for faster ink drying. The air flow system brings air from the rear of the printer and then blows it along the front cover out of the printer. This air flow coupled with a heater makes it possible to quickly dry even low odor inks.
OKI E-64s
Smart dot control algorithm creates rich, bold, glossy colours for superior quality images,drawings, labels, stickers and other applications with readable fonts as small as 2 point size.
Dynamic Dot Printing (DDP) and Smart Pass 4 (SP4) technology for great quality results
SX ink with high viscosity and pigmentation is designed for high performance and most large format printing requirements
Easy-to-use software including CP Manager to control the printer from a PC, smart nozzle mapping and optional features
| Printing Technology | Drop-on-demand Piezo Inkjet Technology |
|---|---|
| Maximum Media Width | 1626 mm(64") |
| Maximum Print Width | 1616 mm(63.6") |
| Margin Size | 5 mm on each edge (with rolled media, without edge guards) |
| Maximum Media Weight | 24 kg |
| Maximum Media Diameter | 180 mm |
| Media | Solvent printer oriented media such as PVC and Banner. |
| Ink Type | Low-Odor and Eco-Solvent SX Ink |
| Color | 6 (Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta) |
| Maximum Ink Capacity | 6-color configuration: 500 ml per color (500 ml per cartridge) |
| Maximum Resolution | 1080 dpi |
| Number of Nozzles | 254 nozzles/head |
| Number of Print Heads | 6 (for 6-color configuration) |
| Maximum Print Speed | 22.9 smph |
| Distance Accuracy *1 | ±0.3% or ±0.5mm, whichever greater |
| Paper Feed Method | Roll Media |
| Head Height | 2 Levels: 2.1 mm or 2.6 mm |
| Heater | 3-way built-in heaters (Pre, Print, After); Max temp. 55 ºC |
| Take-up Mode | LOOSE winding mode with outer take-up TENSION winding mode with outer take-up TENSION winding mode with inner take-up |
| Interface | USB 2.0 (High Speed) |
| RIP | ONYX RIPCenter OKI Edition |
| Power | 120 VAC, 50/60 Hz, 12 A 220 to 240 VAC, 50/60 Hz, 6 A |
| Power Consumption | 1350 W or less |
| Environmental Conditions | Operating: 15 to 30 ºC, 30 to 70 % RH (no condensation) Storage: 5 to 35 ºC, 10 to 80 % RH (no condensation) |
| Dimensions (WxDxH) | 2830 x 830 x 1255 mm |
| Weight | 228 kg or less |
| Included Items | Waste Ink Bottle, USB 2.0 Cable (5m), Power Cord, Cartridge Holder Set, CD-ROM (Utility, Document, Others), Quick Reference Guide, Feed Unit |
The ColorPainter E-64s features Dynamic Dot Printing (DDP) technology together with Smart Pass 4 (SP4) technology to deliver consistently rich, bold, glossy colours with fine details throughout. An in-built production unit provides added flexibility for professional users.
Ideal for a wide range of indoor and outdoor applications, high viscosity SX ink delivers outstanding colour density. It is also odourless, removing the need for an extraction system. High quality indoor applications and long-life outdoor durability - all from one printer.
Built for excellent graphics printing, the versatile ColorPainter E-64s combines Dynamic Dot Printing (DDP) and Smart Pass 4 (SP4) technology. Using several different drop sizes, image quality and colour remain at a superior level, even at the highest print speeds. SP4 uses advanced algorithms and improved mask patterns to reduce overspray and eliminate pass-to-pass banding.
Reliable and easy-to-manage, the ColorPainter E-64s features Smart Nozzle Mapping 3 (SNM3) technology to identify and replace clogged nozzles. Additional CP Manager software enables users to monitor and operate directly from a PC.
Easy-to-use software including CP Manager to control the printer from a PC, smart nozzle mapping and optional features
